Equivalent to:

● Eagle 560

Operating Limits:

● Temperature:-30℃ - +180℃

● Pressure：≤ 10bar

● Speed: ≤ 12m/s

● Shaft size: 10mm - 55mm(560A)/ 0.375" - 3"(560B)/ 16mm - 75mm(560C)

Materials:

● Seal Rings: A,B,Q1/12,Q2/22, U1/12,U2/22

● Elastomer: VITON, EPDM, NBR

● Metal Part: SS304

Assembly Dwg:

Dimensions (mm):

560-A
D1	D3	D6	D7	L1	L3
10	23.5	16	24	25	7
11	23.5	16	24	25	7
12	26	17	26	25	7
14	28	21	28	25.5	7
15	30	21	28	29.5	7
16	32	22	32	33.5	10
18	32.5	25	35	36.5	10
19	32.5	25	35	36.5	10
20	35.5	27	38	38	10
22	37.5	29	40	40.3	10
25	42	32	44	39.3	10
28	47	34	46	40	10
30	46	35	45	38.2	7.5
30	48	38	50	40	10
32	50	40	54	40	10
35	54.5	44	58	42	10
38	58.5	46	60	42.6	10
40	62.5	48	64	42.6	10
45	66.5	52	66	45	10
50	72.5	58	72	54.6	11.5
55	72	60	75	59.4	12

560-B
Size(inch)	D1	D3	D7	L1	L3
0.375	9.53	21	22.2	28.5	6.3
0.500	12.7	23	25.4	30.2	8
0.625	15.88	26.5	31.8	32.5	10.3
0.750	19.05	30.5	35	32.5	10.3
0.875	22.23	34	38.1	34.3	10.3
1.000	25.4	40	41.3	36.4	11
1.125	28.58	44.5	44.5	38	11
1.250	31.75	46.5	47.7	38	11
1.375	34.93	51.5	50.8	39.5	11
1.500	38.1	54	54	39.5	11
1.625	41.28	58	60.3	47.7	12.7
1.750	44.45	61.5	63.5	47.7	12.7
1.875	47.63	65.5	66.7	50.7	12.7
2.000	50.8	70.5	69.9	50.7	12.7
2.125	53.98	75	76.2	57.3	14.3
2.250	57.15	79	79.4	57.3	14.3
2.375	60.33	82	82.6	60.3	14.3
2.500	63.5	86	85.7	60.3	14.3
2.625	66.68	91.5	85.7	65	16
2.750	69.85	91.5	88.9	65	16
2.875	73.03	99	95.3	68.5	16
3.000	76.2	99	98.4	68.5	16

560-C
D1	D3	D7	L1	L3
16	26.5	27	36	10.3
18	30.5	33	37.5	10.3
20	34	35	37.5	10.3
22	34	37	38.2	11
24	40	39	40	11
25	40	40	40	11
28	44.5	43	42.5	11
30	46.5	45	42.5	11
32	46.5	48	42.5	11
33	50.5	48	42.5	11
35	51.5	50	42.5	11
38	54	56	45	11
40	58	58	45	12.7
43	61.5	61	45	12.7
45	61.5	63	45	12.7
48	65.5	66	45	12.7
50	70.5	70	47.5	12.7
53	74	73	47.5	13.5
55	76	75	47.5	14.2
58	79	78	52.5	14.2
60	82	80	52.5	14.2
63	87	83	52.5	14.2
65	85	85	52	16
68	91.5	90	52	16
70	91.5	92	60	16
73	99	93	60	16
75	99	97	60	16

*Related Introduction*

The sealing surface of the mechanical seal must have a certain specific pressure in order to achieve a sealing effect. This requires a certain amount of compression of the spring of the mechanical seal to give a thrust to the sealing end surface, and rotate to make the sealing surface produce the required ratio of the seal. Pressure. In order to ensure this specific pressure, the mechanical seal requires the pump shaft not to have too much displacement, generally within 0.5 mm. However, in the actual design, due to the unreasonable design, the pump shaft often produces a large amount of displacement, which is very unfavorable to the use of the mechanical seal. This phenomenon often occurs in multi-stage centrifugal pumps, especially when the pump is started, the amount of channeling is relatively large.

Hot Tags: 560 mechanical seal, China, suppliers, manufacturers, factory, customized, buy, quality, pricelist, quotation, low price, made in China, MG1 MG12 MG13 Mechanical Seal, mechanical seals, component mechanical seal, Hidrostal PUMP SEALS, 502 Mechanical Seal, rubber bellow seal

560 Mechanical Seal
