Metal Bellows Seal Burgmann For MFL85N Seal

Through the introduction of high-tech equipment and manufacturing technology, relying on premium products and perfect after-sales service, we continuously increase market share and strive to become a high-quality 5610 Cartridge Seals, Rubber Bellows Mechanical Seals, BIA Mechanical Seal supplier in the industry. We welcome you to definitely join us in this path of making a affluent and productive business together. We have a large number of professional and technical personnel with a sense of collectivism, as well as sophisticated CNC machining equipment and sophisticated testing instruments, so that the pass rate of products can reach higher.

Equivalent to:

● Eagle Burgmann Type MFL85N

Operating Limits:

● Temperature:-20℃ - +350℃

● Pressure：­­≤ 21bar

● Speed: ­≤ 23m/s

● Shaft size: 16mm - 100mm

Materials:

● Seal Rings: A,B,Q1/12,Q2/22, U1/12,U2/22

● Elastomer: VITON, EPDM, NBR, FFKM, AFLAS

● Metal Part: SS304, SS316, 4J42, 2CR13, AM350, Hastelloy C, Inconel 718

Assembly Dwg:

Dimensions (mm):

*Related Introduction*

The basic principles of mechanical seal selection:

(1) According to the pressure of the sealed cavity, it is determined that the sealing structure adopts balanced or unbalanced, single end face or double end face, etc.

(2) According to the working speed, determine whether to use the rotary or static, fluid dynamic pressure or non-contact type.

(3) According to the temperature and fluid properties, determine the friction pair and auxiliary sealing materials, and correctly select the mechanical seal circulation protection system such as lubrication, flushing, heat preservation, and cooling.

(4) According to the effective space for installing the seal, determine the use of multiple springs, single springs or wave springs, built-in or external.

Our mature manufacturing technology, strong research and development strength, and advanced production technology ensure that all our Metal Bellows Seal Burgmann For MFL85N Seal are of quality. We have formed a circular economy development model with innovation as the main feature, achieving a win-win situation of energy saving and emission reduction and environmental protection. We believe that every employee of the enterprise is a buildable material, but how to use this resource to the maximum is a subject that needs to be studied with great effort.
