Elastomer Bellow Mechanical Seal Pump Seal Replace for Eagle Burgmann Mg12 Type

Our cartridge seals, bellow mechanical seal, mechanical seal face does have good quality and each of them is strictly inspected to meet industry standards. No matter how demanding the customers are, how urgent the delivery date is, and how complicated the after-sales service is, we are able to cope with them all. Our company makes full use of the opportunities and conditions provided by trade liberalization to actively implement the transnational business strategy. We adhere to the people-oriented principle, develop harmoniously with employees, customers and the environment, and make progress and common prosperity together.

Equivalent to:

● Eagle Burgmann MG1/MG12/MG13

● AESSEAL B02/B012/B013

● Vulcan 191/192/193

Operating Limits:

● Temperature:-20℃ - +200℃

● Pressure：≤ 16bar

● Speed: ≤ 10m/s

● Shaft size: 12mm-120mm

Materials:

● Seal Rings: Resin Carbon, Antimony Carbon, SIC, SSIC, Tungsten Carbide

● Elastomer: VITON, EPDM, NBR, FFKM, AFLAS

● Metal Part: SS304, SS316

Assembly Dwg:

Dimensions (mm):

D1	D2	D6	D7	D3	L1	L12	L13	L5	L6	L7	L8	L9	L10	L12	L14	L15	L16	L28	D11	D12	D8
10	15.7	17	21	22.5	14.5	25.9	33.4	1.5	4	8.5	17.5	10	7.5	7.5	6.6	1.2	3.8	6.6	15.5	19.2	3
12	17.7	19	23	25	15	25.9	33.4	1.5	4	8.5	17.5	10	7.5	6.5	5.6	1.2	3.8	6.6	17.5	21.6	3
14	19.7	21	25	28.5	17	28.4	33.4	1.5	4	8.5	17.5	10	7.5	6.5	5.6	1.2	3.8	6.6	20.5	24.6	3
15	20.8	–	–	28.5	17	28.4	33.4	–	-	–	–	–	–	7.5	6.6	1.2	3.8	–	20.5	24.6	-
16	21	23	27	28.5	17	28.4	33.4	1.5	4	8.5	17.5	10	7.5	8.5	7.5	1.5	5	6.6	22	28	3
18	23.7	27	33	32	19.5	30	37.5	2	5	9	19.5	11.5	8.5	9	8	1.5	5	7.5	24	30	3
19	26.7	–	–	37	21.5	30	37.5	–	-	–	–	–	–	–	–	–	–	–	–	–	-
20	26.7	29	35	37	21.5	30	37.5	2	5	9	19.5	11.5	8.5	8.5	7.5	1.5	5	7.5	29.5	35	3
22	27.7	31	37	37	21.5	30	37.5	2	5	9	19.5	11.5	8.5	8.5	7.5	1.5	5	7.5	29.5	35	3
24	31.2	33	39	42.5	22.5	32.5	42.5	2	5	9	19.5	11.5	8.5	8.5	7.5	1.5	5	7.5	32	38	3
25	31.2	34	40	42.5	23	32.5	42.5	2	5	9	19.5	11.5	8.5	8.5	7.5	1.5	5	7.5	32	38	3
28	35	37	43	49	26.5	35	42.5	2	5	9	19.5	11.5	8.5	10	9	1.5	5	7.5	36	42	3
30	37	39	45	49	26.5	35	42.5	2	5	9	19.5	11.5	8.5	11.5	10.5	1.5	5	7.5	39.2	45	3
32	40.2	42	48	53.5	27.5	35	47.5	2	5	9	19.5	11.5	8.5	11.5	10.5	1.5	5	7.5	42.2	48	3
33	40.2	42	48	53.5	27.5	35	47.5	2	5	9	19.5	11.5	8.5	12	11	1.5	5	7.5	44.2	50	3
35	43.2	44	50	57	28.5	35	47.5	2	5	9	19.5	11.5	8.5	12	11	1.5	5	7.5	46.2	52	3
38	46.2	49	56	59	30	36	46	2	6	9	22	14	10	11.3	10.3	1.5	5	9	49.2	55	4
40	48.8	51	58	62	30	36	46	2	6	9	22	14	10	11.8	10.8	1.5	5	9	52.2	58	4
42	51.8	–	–	65.5	30	36	51	–	-	–	–	–	–	13.2	12	2	6	–	–	–	-
43	51.8	54	61	65.5	30	36	51	2	6	9	22	14	10	13.2	12	2	6	9	53.3	62	4
45	53.8	56	63	68	30	36	51	2	6	9	22	14	10	12.8	11.6	2	6	9	55.3	64	4
48	56.8	59	66	70.5	30.5	36	51	2	6	9	22	14	10	12.8	11.6	2	6	9	59.7	68.4	4
50	58.8	62	70	74	30.5	38	50.5	2.5	6	9	23	15	10.5	12.8	11.6	2	6	9.5	60.8	69.3	4
53	62.2	65	73	78.5	33	36.5	59	2.5	6	9	23	15	12	13.5	12.3	2	6	11	63.8	72.3	4
55	64.2	67	75	81	35	36.5	59	2.5	6	9	23	15	12	14.5	13.3	2	6	11	66.5	75.4	4
58	67.2	70	78	85.5	37	41.5	59	2.5	6	9	23	15	12	14.5	13.3	2	6	11	69.5	78.4	4
60	70	72	80	88.5	38	41.5	59	2.5	6	9	23	15	12	14.5	13.3	2	6	11	71.5	80.4	4
65	75	77	85	93.5	40	41.5	69	2.5	6	9	23	15	12	14.2	13	2	6	11	76.5	85.4	4
68	78	81	90	96.5	40	41.2	68.7	2.5	7	9	26	18	12.5	14.9	13.7	2	6	11.3	82.7	91.5	4
70	80	83	92	99.5	40	48.7	68.7	2.5	7	9	26	18	12.5	14.2	13	2	6	11.3	83	92	4
75	85.5	88	97	107	40	48.7	68.7	2.5	7	9	26	18	12.5	15.2	14	2	6	11.3	90.2	99	4
80	90.5	95	105	112	40	48	78	3	7	9	26.2	18.2	13	16.2	15	2	6	12	95.2	104	4
85	96	100	110	120	41	46	76	3	7	9	26.2	18.2	15	16	14.8	2	6	14	100.2	109	4
90	102	105	115	127	45	51	76	3	7	9	26.2	18.2	15	16	14.8	2	6	14	105.2	114	4
95	107	110	120	132	46	51	76	3	7	9	25.2	17.2	15	17	15.8	2	6	14	111.6	120.3	4
100	112	115	125	137	47	51	76	3	7	9	25.2	17.2	15	17	15.8	2	6	14	114.5	123.3	4

Related Introduction

The importance of the use of fluid mechanical seal technology: The fluid mechanical seal used in mechanical production applications, especially in the process industry, is generally facing the risk of leakage. Leakage will not only cause energy waste, material loss, environmental pollution, but also cause fires, cause explosions, and directly endanger personal safety. Although mechanical seals are small, they determine the safety, reliability and durability of machinery and equipment. Especially for the machinery and equipment of petrochemical enterprises, most of the media handled are corrosive, toxic or flammable and explosive, accompanied by relatively high pressure and temperature. Once leaked, it will often cause major accidents.

It can be seen that fluid mechanical seal technology is not only an effective means to solve the leakage of machinery and equipment to achieve safe production, but also a guarantee for saving resources and protecting the environment, which has attracted widespread attention from all countries in the world.

We implement the concept of "innovation leads the trend" to provide customers with more specialized services and personalized Elastomer Bellow Mechanical Seal Pump Seal Replace for Eagle Burgmann Mg12 Type, and look forward to our joint cooperation and development. The company is strengthening the upgrading and transformation of production equipment, and is preparing to transform to intelligence and equipment modernization. We advocate the virtue of physical strength, hard work and pioneering staff.
